Management of Fournier’s gangrene using skin graft by bagging techniques of testes: A case report.

Citation: AlBurshaid H, AlShehri Y, AlBassam L, et al. Management of Fournier’s gangrene using skin graft by bagging techniques of testes: A case report. Surg Case Rep. 2018;2(2):30-31.

This open-access article is distributed under the terms of the Creative Commons Attribution Non-Commercial License (CC BY-NC) (http://creativecommons.org/licenses/by-nc/4.0/), which permits reuse, distribution and reproduction of the article, provided that the original work is properly cited and the reuse is restricted to noncommercial purposes. For commercial reuse, contact reprints@pulsus.com

Abstract

AIM: To share our experience with the management of Fourniergangrene using the bagging technique of the testes. and to highlight theimportance of implementing a multidisciplinary approach in managing FG. CASE REPRESENTATION: A 58-year-old male with type 2 diabetesmellitus (DM) was brought to the emergency department (ED) with necrotizing fasciitis involving the genitalia; he was managed in the ED withIntravenous (IV) fluid resuscitation and IV antibiotics. The surgical team wasconsulted and multiple debridement procedures were done. Healthygranulation tissue was formed within one month of the serial debridement.A split-thickness skin graft using bagging technique of the testes and vacuum-assisted closure (VAC) were applied. The patient was reassessed one year following presentation, and a result with a near normal appearance wasachieved with complete preservation of functional outcome. CONCLUSION: FG is a type of necrotizing fasciitis that could bemanaged either conservatively with IV antibiotics and/or hyperbaricoxygen, or surgically by debridement and applying VAC. In our case, the testes were debrided and bagging technique of the testes was used. It’sbelieved that with this technique, the overall cosmetic and functional results are superior.

Keywords

Fournier; Bagging technique; Testes; Gangrene; Skin graft

Necrotizing fasciitis (NF) is a life-threatening condition that’s caused by toxin-producing bacteria and affects the fascia [1]. One type of NF is Fournier gangrene, which mainly involves the inguinal and genital area [2]. Jean Fournier, a dermatologist and venereologist, first described FG clinically in the late 1800’s. He described it as an idiopathic fulminant gangrene of males’ inguinal and genital region that occurs rapidly and progressively [3]. This rare and fatal infection, which mostly affects immunocompromised individuals, is a result of both aerobic and anaerobic bacteria [2,3]. Yilmazlar et al. found that Escherichia Coli was the most commonly identified microorganism in these cases [4]. Early diagnosis, antibiotic treatment, surgical debridement and reconstruction of the affected area are the main aspects of managing this condition [5]. In addition to these main steps, bagging technique of the testes was done, in which, both testes were covered together with a split-thickness skin graft. With this technique, a near normal appearance and a complete functional outcome were achieved.

Clinical Presentation

A 58-year-old male who is known to have type 2 diabetes mellitus (DM) presented to the emergency department (ED) with fever, vomiting, scrotal pain and swelling. After being thoroughly evaluated in the ED, the patient was clinically diagnosed with Fournier’s gangrene. Intravenous (IV) fluid resuscitation was initiated, IV antibiotics were given, and the surgical team (including urology and plastic surgery) was consulted. The patient was shifted to the operating room (OR) where debridement was done by the urology team (Figure 1).

Figure 1: Necrotic tissue of the genitalia was extensively debrided

The testes were temporarily relocated to the anteromedial side of the thighs in order to achieve an optimum scrotal wound closure (Figure 2).

Figure 2: Testes were relocated in the anteromedial side of the thighs. Granulation tissue has been formed

Following that, he underwent surgical debridement of the scrotum and penis four times, and vacuum-assisted closure (VAC) was applied to enhance wound healing (Figure 3).

Figure 3: VAC was applied to aid formation of granulation tissue

A healthy granulation tissue was formed over the wound within one month of serial debridement. Repositioning of the testes to their natural position was done and they were both sutured together by absorbable sutures. A splitthickness skin graft was used in three units to reconstruct the defect in the penis and inguinal area. The bagging technique was done by harvesting the skin from the back and was applied from the base of the penis and brought into the frontal part of it. The testes were approximated at the midline and were attached together with small sutures (Figure 4).

Figure 4: Testes were approximated and the bagging technique was done using the skin graft

After that, a mini abdominoplasty was done to the patient for a more enhanced shape and satisfactory result. A cosmetically appealing and satisfactory result was achieved after two months and patient was discharged home with good urological and sexual function (Figure 5). The patient was reassessed one year following the surgery and was satisfied and with no complications.

Figure 5: Satisfactory healing and cosmetically appealing result was achieved after two months

Discussion

FG is known to be a type of necrotizing fasciitis that affects the external genitalia, including the penis and scrotum of immunocompromised individuals [5,6]. FG has many predisposing factors, the most common one being diabetes mellitus with an incidence of 46-76.9% [7-9]. Other factors that may contribute to the condition include alcoholism, malignancy, obesity and extremes of age [5,6]. Fournier’s gangrene is believed to be polymicrobial in origin, caused by both aerobic and anaerobic organisms that invade the area through skin abrasions caused by trauma or ulceration. This, along with the favorable environment for bacteria to grow that is found in high-risk individuals all contribute to the emergence of the disease [7]. In the majority of reported cases, there are underlying causes that may trigger FG including anal abscesses or trauma caused by a certain medica interventions to the scrotum or perineum [8]. However, in our case no cause was found. Despite advances in the medical field, the mortality rate of FG remains as high as 67%; thus, proper management steps should be carefully followed [9]. Early recognition and diagnosis, aggressive antibiotic administration, fluid resuscitation, extensive surgical debridement are all important determinants of the outcome [3,9]. Today, the gold standard therapy for Fournier’s gangrene is early and complete surgical debridement [10,11]. Defects where large areas of tissue are lost necessitate reconstruction of the region by skin grafts or flaps [5]. Other treatment modalities include hyperbaric oxygen (HBO) therapy [12-15], which is a widely accepted method that may help in the management of severe cases. Wound healing may be accelerated by using urinary and fecal diversion techniques [16].

Conclusion

Fournier’s gangrene is known to be a surgical emergency [13]. One of the important risk factors leading to this condition is Diabetes Mellitus [10]. Management of FG includes administration of IV antibiotics, fluid resuscitation and prompt surgical debridement and reconstruction by either skin flaps or grafts [14]. Hyperbaric oxygen (HBO) therapy [15] has proven beneficial in managing severe cases. Acceleration of wound healing may be achieved by diversion of urine and feces away from the affected area [16]. In our case, skin grafts were applied using the bagging technique of the testes, which resulted in a satisfactory cosmetic and functional result.

Conflict of Interest

All authors state that they have no conflict of interests.

Consent

Informed consent was obtained from the patient.

REFERENCES

1. Green R, Dafoe D, Rajfin T. Necrotizing fasciitis. Chest. 1996;110(1):219-29.
2. Thwaini A. Fournier's gangrene and its emergency management. Postgrad Med J. 2006;82(970):516-9.
3. Heiner J, Eng K, Bialowas T, et al. Fournier's gangrene due to masturbation in an otherwise healthy male. Case Rep Emerg Med. 2012;2012:1-3.
4. Yilmazlar T, Gulcu B, Isik O, et al. Microbiological aspects of Fournier's gangrene. International Journal of Surgery. 2017;40:135-8.
5. Nickel J, Morales A. Necrotizing fasciitis of the male genitalia (Fournier's gangrene). CMAJ. 2018.
6. Mallikarjuna M, Vijayakumar A, Patil V, et al. Fournier’s gangrene: Current practices. ISRN Surgery. 2012;2012:1-8.
7. Milovic N, Bancevic V, Campara Z, et al. Fournier's gangrene. Vojnosanitetski pregled. 2008;65(10):775-8.
8. Chen Y, Wang X, Lin G, et al. Successful treatment following early recognition of a case of Fournier’s scrotal gangrene after a perianal abscess debridement: A case report. 2018.
9. Norton K, Johnson L, Perry K, et al. Management of Fournier's gangrene: An eleven-year retrospective analysis of early recognition, diagnosis, and treatment. Am Surg. 2018;68:709-13.
10. Taken K, Oncu MR, Ergun M, et al. Fournier's gangrene: Causes, presentation and survival of sixty-five patients. Pakistan Journal of Medical Sciences Quarterly 2016;32(3):746-50.
11. Pernetti R, Palmieri F, Sagrini E, et al. Fournier's gangrene: Clinical case and review of the literature. Archivio italiano di urologia, andrologia: Organo ufficiale [di] Societa italiana di ecografia urologica e nefrologica. 2016;88:237-8.
12. Rajan P, Raza A, Pemberton R, et al. Testicular torsion following a skin graft for Fournier's gangrene. International Journal of Clinical Practice. 2009;63(1):176-7.
13. Hota P. Fournier's gangrene: Report of 2 cases. Case Reports in Emergency Medicine. 2012;2012:1-4.
14. Karian L, Chung S, Lee E. Reconstruction of defects after Fournier gangrene: A systematic review. J Plast Surg. 2015;15.
15. Sakalis V, Giouris A, Gkotsi A, et al. s112 is an early urinary and fecal diversion beneficial in patients presenting with Fournier gangrene?. 2018.
16. Milanese G, Quaresima L, Dellabella M, et al. A conservative approach to perineal Fourniers gangrene. Archivio Italiano di Urologia e Andrologia. 2015;87(1):28.
