*Corresponding Author:
Dr Sophie Mavrogeni
Department of Onassis Cardiac Surgery
Center,Greece,50 Esperou Street
175-61 P.Faliro, Athens, Greece
Tel/fax 30-210-98-82-797
E-mail: soma13@otenet.gr

This open-access article is distributed under the terms of the Creative Commons Attribution Non-Commercial License (CC BY-NC) (http:// creativecommons.org/licenses/by-nc/4.0/), which permits reuse, istribution and reproduction of the article, provided that the original work is properly cited and the reuse is restricted to noncommercial purposes. For commercial reuse, contact support@pulsus.com

[ft_below_content] =>

Keywords

Cardiovascular magnetic resonance imaging; Heart failure; Muscular dystrophies

Muscular dystrophies (MD) constitute a heterogeneous group of inherited disorders characterized by progressive skeletal muscle atrophy and weakness. Diagnosis is based on the severity of muscular disease and type of inheritance, confirmed by genetic assessment. Cardiac disease is common in MD and is not necessarily related to the severity of skeletal myopathic disease; on the contrary, heart involvement may be the presenting or predominant manifestation of MD in some cases, without any other evidence of muscular disease. Cardiac death in these patients is usually due to ventricular dysfunction, heart block and/or malignant arrhythmias. Recently, increased survival rates due to better management of lung disease have emphasized the role of heart disease as an important contributor to the mortality of MD [1]. Cardioprotective medical treatment may delay the development of heart disease; therefore, early diagnosis is essential for MD patients’ survival [2-6]. Clinical evaluation, electrocardiography (ECG) and echocardiography are the classic screening tools [7,8]; cardiovascular magnetic resonance imaging (CMR) may be of considerable value for early detection of cardiac disease – which may remain silent for long periods – due to its capability to characterize tissue [9,10].

Skeletal Muscle Diseases Commonly Associated with Cardiac Involvement

Dystrophin-associated diseases (dystrophinopathies)

Dystrophinopathies include Duchenne muscular dystrophy (DMD), Becker muscular dystrophy (BMD), X-linked dilated cardiomyopathy (XLCM) and facioscapulohumeral muscular dystrophy (FSHD). DMD and BMD are X-linked disorders affecting the synthesis of dystrophin, a large sarcolemmal protein that is absent in DMD [11], and reduced in amount or abnormal in BMD [12]. The incidence of DMD is one in 3500 male newborns with a prevalence of six in 100,000 males [13]. DMD is characterized by weakness of the leg, pelvic and shoulder girdle muscles starting in early childhood. DMD and BMD account for >80% of all causes of MD.

Dystrophin provides the connection between a large complex of glycoproteins in the muscle cell membrane (called the dystrophinglycoprotein complex) and intracellular actin filaments, transmitting forces generated by sarcomere contraction to the extracellular matrix [14,15]. Absence, reduced levels or abnormal structure of dystrophin leads to membrane fragility, making muscle fibres prone to injury during contraction [16]. As muscle disease progresses, muscle repair cannot adequately compensate for damage, leading to necrosis of skeletal and cardiac myocytes and progressive replacement by fibrofatty tissue [17].

BMD is a milder variant of dystrophinopathy with a better prognosis. Incidence of BMD is one in 18,450 males and prevalence is 2.4 per 100,000 in the general population [11,18]. The first symptoms appear between three and 21 years of age, with a mean age of onset of 11 years. The age at death is 21 to 89 years (mean age approximately 45 years) [19-22].

XLCM is a primary myocardial dystrophinopathy, presenting as congestive heart failure in teenage males, with almost no skeletal muscle disease. It is characterized by rapid progression, leading to cardiac death within one to two years. The distinction between XLCM and BMD with mild skeletal muscle weakness is difficult. Therefore, these entities are considered to be part of the same disease expression [23].

FSHD is the third most common MD (after DMD and myotonic dystrophy), with an estimated prevalence of one per 20,000 in the adult European population [24].

Cardiac disease in dystrophinopathies

After the third decade of life, the majority of DMD patients have established cardiomyopathy [25]. Although clinically overt heart failure may be delayed or absent due to relative physical inactivity, cardiomyopathy is the leading cause of death in DMD and myocardial damage precedes decline in left ventricular (LV) systolic function. Neither the age of onset nor the severity of cardiomyopathy is correlated with the type of mutation [26]. It was recently documented that in DMD with preserved ejection fraction, the addition of eplerenone to background angiotensin-converting enzyme inhibitors or angiotensin II receptor blockers attenuates the progressive decline in LV systolic function [27].

Cardiomyopathy is the main clinical complication in patients affected by subclinical or mild BMD. The clinical presentation is usually characterized by early right ventricular dysfunction and is later associated with LV impairment. In mild BMD, myocardial damage may develop because the patients, who are unaware of a possible cardiac disease, can still perform strenuous muscle exercise and, through pressure or volume overload, may induce mechanical stress, which is harmful for dystrophin-deficient myocardial cells [28].

Cardiac involvement in female carriers of dystrophinopathies

Cardiac disease in female carriers of dystrophinopathies may present as hypertrophy, arrhythmias or dilated cardiomyopathy [29]. The percentage of patients with clinically overt cardiac involvement increases significantly with age, from 15% in carriers <16 years of age to 45% in carriers ≥16 years of age. In contrast, significant cardiac disease is unlikely in female carriers <16 years of age [30]. In a crosssectional study involving 85 DMD and 44 BMD carriers 18 to 58 years of age, LV dilation and dilated cardiomyopathy were observed in 18% and 8%, respectively [31]. ECG abnormalities were found in only 47% of this population [32]. Another series of 56 adult female carriers did not present any ECG abnormalities, but ventricular dilation or hypertrophy was documented in 14% and dilated cardiomyopathy in 7% [33]. Nevertheless, severe heart failure may develop in some women, necessitating heart transplantation [29,34,35]. Exercise may unmask LV systolic dysfunction in female carriers [36]. In a study conducted by our group, CMR revealed myocardial fibrosis in the majority of DMD and BMD mother-carriers, although the clinical presentation and the usual noninvasive assessment were mildly abnormal [37]. Therefore, detailed cardiac evaluation, at least once after the teenage years, should be recommended for all female carriers to enable an early start of cardiac treatment [38]. XLCM female carriers have later onset, typically during the fifth decade of life, and slow progression of heart failure [39].

Emery-Dreifuss MD

Emery-Dreifuss MD (EDMD) is characterized by early contractures of the elbows, Achilles tendons (toe walking), posterior cervical muscles (rigid spine) and muscle weakness in a humeroperoneal distribution. Joint contractures occur early, typically before the development of any significant weakness. EDMD can be X-linked or autosomal; X-linked recessive EDMD (EDMD1) has a prevalence of one in 100,000 males. EDMD1 is caused by various mutations in the STA gene [40]. The protein product (emerin) is a member of a protein complex that links filamentous actin in the cytoskeleton to the nuclear lamina and/or chromatin [41,42]. Autosomal dominant EDMD (EDMD2) and a rare autosomal recessive form of EDMD are caused by a mutation in the lamin A/C gene [43,44] with unknown prevalence. Lamin A/C codes for alternatively spliced lamins A and C. Additionally, lamin A/C mutations can cause several other phenotypes, including limb-girdle MD (LGMD) type 1B, autosomal dominant dilated cardiomyopathy with conduction defects (CMD1A), autosomal-recessive EDMD, autosomal-recessive axonal neuropathy, familial partial lipodystrophy, mandibuloacral dysplasia and progeria syndromes, all referred to as laminopathies.

Cardiac disease in EDMD

In EDMD1, the most common cardiac finding is conduction disturbances [45]. LV dysfunction and atrial paralysis can also be observed [46,47]. Sudden death is common and highly unpredictable [48,49]; therefore, pacemakers are often needed at 30 years of age (range 14 to 44 years) [50-53]. Heart failure and atrial or ventricular arrhythmias occur only in a minority of patients; however, the risk may increase as patients with a pacemaker survive longer [47,49].

Cardiac involvement in female carriers of EDMD

Female carriers of an emerin mutation have no muscular symptoms, although some may be at risk for cardiac arrhythmias and sudden death [52-55]; however, studies investigating cardiac involvement in EDMD1 carriers are not available.

LGMD

LGMD consist of a heterogeneous group of MD with involvement of pelvic and shoulder girdle musculature [55]. Seven autosomal dominant (LGMD1A to LGMD1G) and 14 autosomal-recessive forms (LGMD2A to LGMD2 M) have been already recognized as genes responsible for LGMD. LGMD type 2A is caused by mutations in the calpain 3 gene (CAPN3) and complete lack of functional CAPN3 leads to the most severe muscle wasting. CAPN3 is suggested to be involved in maturation of contractile elements after muscle degeneration [55].

The disease course of autosomal dominant LGMD is usually relatively mild and the age of onset ranges from childhood to the fourth decade of life [56]. The clinical presentation of autosomal-recessive LGMD is more severe and resembles that of dystrophinopathies [56]. The prevalence of all forms of LGMD ranges from one in 23,000 to one in 150,000 [2,56]. Disruption of proteins that mediate sarcolemmal repair or other cell-signalling pathways and defective enzymes can result in the limb-girdle dystrophic phenotype [57]; however, the exact functional role of the affected proteins and the precise pathogenic mechanism leading to LGMD remains unknown.

Cardiac disease in LGMD

LGMD1: Cardiomyopathy was reported in allelic disorders with mutations in myotilin (myofibrillar myopathies) and caveolin-3 (autosomal dominant rippling muscle disease), which may overlap with LGMD1A and C, respectively. LGMD1E has been reported in only one family [58]. The phenotype is similar to LGMD1B. Dilated cardiomyopathy with conduction defects and/or adult-onset LGMD and sudden death, despite pacemaker therapy, has been described [58].

LGMD2C, 2D, 2E and 2F: These types of LGMD are caused by mutations in the transmembrane proteins of the sarcoglycan complex. The prevalence of sarcoglycanopathies is approximately one in 178,000 [59]. LGM2D is the most frequent sarcoglycanopathy, followed by LGMD2E andLGMD2C, while LGMD2F is the least common [59-61]. Disease severity is related to the percentage of residual sarcoglycan protein. Mild ECG and/or echocardiographic changes occur in 20% to 30% of sarcoglycanopathy [62,63]. The risk for cardiac involvement is low in LGMD2D; however, dilated cardiomyopathy and ventricular arrhythmias may occur in LGMD2E with severe DMD-like dystrophy [64,65]. Although a correlation between genotype/phenotype and prognosis has not yet been established, detailed evaluation of sarcoglycanopathies for cardiac disease is necessary [66].

LGMD2I: LGMD2I is caused by mutations in the fukutin-related protein (FKRP) gene [67]. Mutant FKRP directly or indirectly disturbs glycosylation of the transmembrane protein a-dystroglycan in muscle cells. Appropriate glycosylation is necessary for a-dystroglycan to bind components of the extracellular matrix, including laminin-2 [68].

Cardiac involvement has been reported in 29% to 62% of patients with LGMD2I [69-73]. LV wall motion changes and dilated cardiomyopathy may begin as early as the teenage years. A significant percentage of patients may develop symptomatic heart failure over time, beginning at a mean age of 38 years (range 18 to 58 years) [70]; this is not always associated with severe muscle weakness [67,70]. LGMD2I patients are also at risk for respiratory impairment and may require nocturnal ventilation [69,70].

Myotonic dystrophy

Myotonic dystrophy type 1 (DM1) is an autosomal-dominant muscular dystrophy caused by expansion of cytosine-thymine-guanine (CTG) trinucleotide repeats in the myotonic dystrophy protein kinase (DMPK) gene. DM1 is the most common MD in adults. It has a prevalence of 2.1 to 14.3 per 100,000 worldwide, although its prevalence is higher in certain populations due to genetic isolation [74]. Muscle involvement is characterized by myotonia and weakness of the facial, sternocleidomastoid and distal muscles, combined with systemic manifestations including cataract, gastrointestinal, central nervous system and cardiac abnormalities. Based on age at onset and symptoms, four clinical categories have been distinguished: congenital; childhood; classical (adultonset); and mild (late-onset) type [75]. Life expectancy is reduced in DM1, mainly in those with early disease onset and proximal muscle(s) involvement [76]. Median survival is 59 to 60 years for patients with adult onset and 35 years for patients with the congenital type [77]. Progressive respiratory failure remains the leading cause of mortality, followed by cardiac death in 20% to 30% of cases [76-78].

Cardiac disease in DM1

Cardiac abnormalities can be diagnosed as early as the second decade of life in the childhood type [79]. Conduction disturbances occur in 65% of adults [80]; pathology studies showed fibrosis of conduction system and diffuse interstitial fibrosis throughout the myocardium [81]. Ventricular dysfunction and structural changes have been documented by both echocardiography and cardiovascular magnetic resonance imaging [82,83]. However, the prevalence of heart failure is approximately 2% to 7% [83,84].

Sudden death is not unusual in DM1, and was initially believed to be due to conduction disturbances. However, reports of sudden death in patients with pacemakers and episodes of sudden death related to well-documented ventricular tachycardia (VT) suggested that VT may be a more frequent cause of sudden death than it was previously believed [78,85]; therefore, prophylactic implantable cardioverterdefibrillator (ICD) implantation should be carefully evaluated in the high risk for sudden death patients with good prognosis of their neuromuscular disease.

Myotonic dystrophy type 2

Myotonic dystrophy type 2 (DM2) is an autosomal dominant disorder resembling adult-onset DM1, but with more favourable prognosis compared with DM1. Three classes of large non-DM2 repeat alleles were identified: up to (CCTG)-24 with two interruptions; up to (CCTG)-32 with up to four interruptions; and uninterrupted (CCTG)-22-33. Large non-DM2 alleles were more common in African Americans than in European Caucasians. Uninterrupted alleles were significantly less stable than interrupted alleles [86].

Patients present with predominantly proximal lower limb weakness or weakness of deep finger flexors [86,87]. A review of 209 DM2 patients reported that first symptoms occurred between 13 and 67 years of age (median age at onset 48 years) [86]. Facial muscle weakness is less severe, myotonia is typically less apparent and muscle atrophy is milder than in DM1. Muscle pain is a major complaint of DM2 and systemic manifestations such as cataract, cardiac and endocrine dysfunction may also coexist. However, in contrast to DM1, respiratory failure is rather unusual [86,87].

Myofibrillar myopathies

Myofibrillar myopathies (MFM) represent a group of genetically disorders, associated with peripheral neuropathy and cardiac disease. MFM present in adult life with slowly progressive muscular weakness.

Desmin-related MFM (desminopathies) may have various phenotypes depending on the type of mutations. Heart disease may precede, coincide with or succeed skeletal disease. Conduction disturbances and arrhythmias are frequent in desminopathies because desmin is an important component of Purkinje fibres [88].

Mutations in a-B crystallin may also cause phenotypic features of desminopathy. Patients with a-B crystallinopathy may develop hypertrophic cardiomyopathy [89,90] and mutation in BAG3 may cause severe childhood MD with cardiomyopathy and respiratory failure [91].

Other MD

Mild to moderate cardiomyopathy was detected in one of three affected family members with late-onset autosomal dominant distal myopathy [92]. Several rare X-linked myopathies are also associated with cardiomyopathy. X-linked vacuolar cardiomyopathy and myopathy (Danon disease) is caused by mutations in the gene encoding lysosome-associated membrane protein-2 (LAMP-2) at Xq24 [93] and cardiac disease is the dominant clinical feature. Skeletal muscle involvement is usually mild, and is observed in 90% of male patients and 33% of female relatives.

A study involving 20 men and 18 women with genetically confirmed Danon disease reported cardiomyopathy in all patients [94]. Men were severely affected before 20 years of age. The most frequent findings were hypertrophic cardiomyopathy with impaired LV function and Wolff-Parkinson-White syndrome. Most affected women developed dilated cardiomyopathy in adulthood. The mean age at death was 19 years in male and 40 years in female patients [94].

Barth syndrome, an X-linked disorder in infancy, characterized by cardiomyopathy, neutropenia, skeletal myopathy and growth delay, is caused by mutations in the taffazin gene at Xq28 that result in cardiolipin deficiency and abnormal mitochondria [92]. Female carriers appear to be healthy. In a study involving 34 men, 90% had dilated cardiomyopathy, 53% had prominent LV trabeculations and ventricular arrhythmias were frequent in adolescents [95].

McLeod syndrome is a late-onset X-linked disorder caused by mutations of XK, a gene of unknown function, and characterized by movement disorders (chorea), cognitive impairment, myopathy and acantocytosis. A few cases of female mutation carriers have been reported [96]. Approximately 65% of individuals develop cardiac disease, including dilated cardiomyopathy, atrial fibrillation and tachyarrhythmia (96).

Mutations in the four-and-a-half LIM domain gene (FHL1) have been identified as causative for reducing body myopathy, X-linked scapuloperoneal myopathy and X-linked myopathy with postural muscle atrophy (XMPMA). FHL1 is highly expressed in skeletal and cardiac muscle. Hypertrophic cardiomyopathy was observed in four of nine XMPMA patients, and dilated cardiomyopathy in one of 11 reducing body myopathy patients [97,98]; however, respiratory failure remains the major cause of death.

An early-onset myopathy with fatal cardiomyopathy, due to homozygous C-terminal TTN deletions, has been described as the only titinopathy involving both heart and skeletal muscle [99].

Mutations in the beta-cardiac myosin heavy chain gene (MYH7) may cause various phenotypes ranging from pure peripheral muscle disease to isolated cardiomyopathies. However, MYH7 mutations combining symptomatic distal myopathy and cardiac involvement have been reported [100,101].

Currently Used Techniques for the Evaluat ion of Heart Involvement in MD ECG

The most common electrocardiographic findings in MD include conduction disease (PR interval ≥210 ms, QRS duration ≥120 ms, left anterior or posterior fascicular hemiblock), arrhythmias (supraventricular or ventricular), hypertrophy (Sokolow-Lyon index ≥35 mm) and evidence of myocardial necrosis, depending on the type of MD.

DMD, the most common and severe form of childhood MD, is associated with increased R/S ratio in the right precordial leads, deep Q waves in the lateral leads, conduction abnormalities and arrhythmias (mainly supraventricular but also ventricular). In a study involving 131 individuals with DMD, ECG was abnormal in 78.6%. All were in sinus rhythm and the following percentages were found for the main variables studied: short PR interval, 18.3%; abnormal R waves in V1, 29.7%; abnormal Q waves in V6, 21.3%; abnormal ventricular repolarization, 54.9%; abnormal QS waves in inferior and/or upper lateral wall, 37.4%; conduction disturbances in right bundle branch, 55.7%; prolonged QT, 35.8%; and wide QRS, 23.6% [102]. The prevalence of incomplete right bundle branch block was significantly higher in patients with FSHD (33% [95% CI 22.6% to 44%]) than in the normal population (1.2% to 3.4%) [103]. Additionally, the prevalence of complete right bundle branch block in FSHD (3.8% [95% CI −0.4% to 8.4%]) tended to be higher than in the normal population (0.16% to 0.8%) [104].

In EDMD, normal myocardium is gradually replaced by fibrous and adipose tissue; this process usually starts in the atria (leading to atrial arrhythmias) or involves the atrioventricular node, leading to conduction abnormalities, sometimes requiring a pacemaker, and finally the ventricles, causing progressive dilation and systolic function failure [105]. Sudden death may be the presenting symptom of EDMD; therefore, cardiac screening of relatives, including female carriers with X-linked EDMD, is recommended [106].

Patients with mutations in the lamin A/C gene (1p1-q21 locus) develop sinus and atrioventricular node dysfunction, ventricular arrhythmias and adult-onset cardiomyopathy with mild skeletal myopathy. The inheritance pattern is autosomal dominant with high penetrance, and patients are at high risk for sudden death [107].

Atrioventricular and intraventricular conduction defects are common in both DM1 and DM2, with infrahisian block being an important cause of sudden death [103]. Additionally, cardiac arrhythmias may occur early during the course of the disease, even in the absence of severe neuromuscular impairment. In a population of 31 DM1 patients, 38% had first-degree atrioventricular block (AVB) and 51% had intraventricular conduction disturbances (62% had late potentials) [108].

Not only ECG but also Holter monitoring is necessary for evaluation of MD patients. Cardiac surveillance, including routine monitoring of electrocardiograms, may detect early DCM development in both DMD and BMD [109]. In addition, in 32% of MD1 patients with a normal ECG, the 24 h Holter monitoring showed arrhythmias and conduction abnormalities [110]. In MD1, Holter monitoring should be performed on a regular basis, at intervals not >6 months [111].

In a study involving MD1 patients including ECG, Holter and echocardiography, a normal ECG was not associated with normal Holter and echo [113]. In another study investigating MD1 using Holter, atrial fibrillation (AF) and atrial flutter (AFL) were frequent in MD1 and lead to increased mortality. AFL could present as 1/1 AFL with a poor tolerance and a risk for misdiagnosis despite frequent conduction disturbances. Another study including 104 DM2 and 117 DM1 patients who underwent baseline and follow-up assessments of ECG, 24 h Holter monitoring, two-dimensional echocardiography and electrophysiological studies, showed that 10% of DM2 patients versus 31% of DM1 patients had PR ≥200 ms and 17% of DM2 patients versus 48% of DM1 patients had QRSD ≥100 ms. Six patients with DM2 versus 28 patients with DM1 required PM/ICD implantations [114]. Holter recording has been used not only for accurate diagnosis of heart rhythm in MD, but also for treatment evaluation [115-118].

Echocardiography

Echocardiography is the most commonly used imaging technique for LV evaluation and has already assessed marked variability in the severity of LV dysfunction in DMD, independently of age of onset or mutation groups [119].

In another study, echocardiograghy identified LV systolic dysfunction in 20.6% and reduced global longitudinal strain in 21.7% of MD1 patients [120]. An echocardiographic study involving sarcoglycanopathy patients detected dilated cardiomyopathy in 17% [121]. Echocardiography also assessed a high prevalence of LV dysfunction in DMD, with frequent evidence of systolic ventricular asynchrony, particularly in patients with ejection fraction <35% [122]. LV dysfunction with reduced LV ejection fraction has been already observed in EDMD [123]. Echocardiography also revealed cardiac involvement in 24% of patients with LGMD2A-I [124]. In a multicentre retrospective analysis of 38 patients with LGMD 2I, 55.3% had cardiac abnormalities, of whom 24% had heart failure. Heterozygotes for the common C826A mutation developed cardiac disease earlier than homozygotes. All patients initially improved, while receiving standard therapy. No correlation between skeletal muscle disease, cardiomyopathy and/or respiratory insufficiency was identified [125]. Structural heart disease is also frequent in myotonic dystrophy, with LV dilation or hypertrophy observed in approximately 20% and LV systolic dysfunction in 14% of patients [126]. Clinically overt heart failure, however, was documented in only 2%, according to the same report. In a study evaluating diastolic heart function in MD1 using echocardiography, an increase of the left atrial diameter and mitral deceleration time suggesting diastolic abnormalities was identified [127]. In cases with a suboptimal acoustic window, three-dimensional echocardiography can serve as an excellent alternative [128].

In a recent case report, the abnormal region identified by voltage mapping was concordant with the segmental impairment in twodimensional strain pattern detected by speckle tracking; this is promising for the application of this technique in the evaluation of MD1 [129]. In DM2, although muscular disease is less prominent, cardiac involvement may be developed; therefore, cardiac evaluation is recommended to identify those at high risk for potential major cardiac events [130].

Finally, echocardiography using transmural strain profile can detect subclinical LV dysfunction in patients with DMD without wall motion abnormalities by conventional echocardiography [131]. The application of myocardial strain imaging in DMD patients was characterized by decreased peak systolic strain of the posterior wall, despite normal standard echocardiographic findings [132]. These studies, although very promising, were not universally accepted for the routine assessment of MD.

Why CMR in MD?

CMR is a noninvasive, nonradiating technique ideal for serial evaluation of cardiac volumes, mass, ejection fraction, inflammation and fibrosis because it is operator independent and has excellent reproducibility [133]. Early indexes, such as strain analysis, may be abnormal in MD before any cardiac dysfunction is detected. CMR tagging showed that DMD patients exhibit abnormal global and segmental circumferential strain compared with age- and sexmatched controls, despite similar LV volumes and ejection fractions [134]. Similar findings showed that abnormal myocardial strain precedes both the age-dependent decrease in ejection fraction and the development of myocardial fibrosis in DMD [134]. Finally, strain analysis is more sensitive to detect serial impairment in LV function compared with LV ejection fraction [135]; therefore, it is of great value to assess treatment efficacy. These indexes, although promising, are not widely accepted and do not represent a robust tool for detection of cardiac involvement in MD.

In contrast, the most robust CMR data are referring to early myocardial fibrosis in DMD, BMD and female carriers, detected by late gadolinium enhancement (LGE). The pathology of cardiomyopathy in dystrophinopathies includes the presence of subepicardial fibrosis in the inferolateral wall [136,37], similar to that observed in viral myocarditis. The application of CMR in MD, in addition to the standard monitoring by echocardiography and ECG, is of great value because early initiation of heart failure treatment may delay the progression of LV dysfunction and/or even reverse cardiac remodelling in X-linked dystrophinopathies [137]; and because myocardial fibrosis, assessed by LGE, may be observed, even if echocardiographic evaluation is still normal [136,138] and CMR may serve as an early sensitive index to motivate the start of cardioprotective treatment. It may also be applied as a screening tool to identify patients at risk for ventricular arrhythmias, more advanced disease, adverse LV remodelling and death [139] (Figure 1). Finally, in mutation carriers, CMR revealed a pattern of fibrosis similar to that observed in DMD [37] (Figure 2), even in the absence of overt muscular disease. Recently, CMR techniques, such as postcontrast myocardial T1 mapping, have been applied in DMD to detect diffuse myocardial fibrosis [140].

current-research-cardiology-Late-gadolinium

Figure 1: Late gadolinium enhancement in the lateral wall of the left ventricle in a patient with Becker muscular dystrophy

current-research-cardiology-Duchenne-muscular

Figure 2: Late gadolinium enhancement in the lateral wall of the left ventricle in a female carrier of Duchenne muscular dystrophy

In EDMD, CMR data are limited due to the rarity of the disease and the frequent pacemaker implantation in this population. Comparative studies using echo and CMR in EDMD showed absence of myocardial fibrosis, despite the presence of more subtle myocardial abnormalities, including a decrease in systolic circumferential strain in the inferior segment, suggesting a different pathophysiology of cardiac disease in EDMD compared with DMD/BMD, where fibrosis usually precedes systolic dysfunction [141].

Heart involvement in LGMD using CMR demonstrated subepicardial pattern of LGE similar to that detected in BMD, suggesting that this damage represents a nonspecific pattern due to increased mechanical stress in this area [142]. However, LGMD2I and LGMD2B usually lead to mild structural and functional cardiac abnormalities, although severe dilated cardiomyopathy may also occur [143]. Another study that evaluated LGMD2I using physical examination, echocardiography, resting and 24 h ambulatory ECG and CMR proved that both the gene mutation and the severity of the muscle disease were not predictive of cardiac involvement; on the contrary, CMR documented a high prevalence of myocardial functional abnormalities, fatty replacement and fibrosis. Reduced contractility and CMR abnormalities were highly prevalent in LGMD2I, suggesting that all patients should be referred for cardiac evaluation [144,145].

Structural alterations of the myocardium, such as fibrosis and fatty infiltration, were also observed in autopsy studies of patients with myotonic dystrophy. CMR evaluation of these patients revealed functional and structural abnormalities in 44% and myocardial fibrosis in 12.5% [146]. Patients with myotonic dystrophy may present with cardiomyopathy, which is usually more benign in DM2 compared with DM1. CMR can define the LV abnormalities of the disease, such as dilation, systolic dysfunction, hypertrophy and, occasionally, noncompaction [147,148]; however, typical LGE patterns have not been observed in this population.

What type of sequences should be included in the CMR evaluation of MD?

CMR, using cine sequences, can measure ventricular volumes and ejection fraction without contrast agent and provides threedimensional images of the heart, also feasible with three-dimensional echocardiography. CMR ejection fraction and volumes are more accurate and reproducible than other imaging techniques; however, there is a good correlation between CMR and other techniques [132]. Echocardiography is still the everyday bedside tool, but CMR is ideal for the serial evaluation of ventricular volumes, mass and function due to its high reproducibility [132].

CMR is the most reliable imaging technique to detect and quantify scar or fibrotic tissue (viability study). Fibrotic/scar lesions retain contrast agent and, therefore, appear bright [149]. The preferred imaging time for scar detection is between 10 min and 20 min after contrast agent administration, when the differences between scar tissue, normal myocardium and the blood pool are maximal. This method is referred as LGE CMR and is the gold standard for the in vivo assessment of myocardial scar. CMR can detect scar tissue in as little as 1 cm3 of tissue, substantially less than other in vivo methods, and has shown excellent agreement with histology [149]. Not only the presence, but also the LGE amount plays an important role in patients’ prognosis, because even a small area of LGE (<2% of LV mass) was associated with a >7-fold increase in risk for a major adverse cardiac event in patients with coronary artery disease [150]. Many studies have documented the presence of myocardial scar in both MD and carriers, emphasizing its role as an early strong diagnostic sign of heart involvement and as a motivating factor for early start of cardiovascular treatment [37,136]. A recent CMR evaluation of patients with nonischemic cardiomyopathy documented that LGE was a powerful and independent predictor of malignant arrhythmic prognosis, while its amount and distribution did not provide additional prognostic value; therefore, it may contribute to identify candidates for ICD therapy not fulfilling the current criteria based on LV ejection fraction [151].

Myocarditis can present in MD under different clinical scenarios (varying from severe hemodynamic collapse to subclinical disease), is undetectable by blood inflammatory indexes and may lead to dilated cardiomyopathy. MD patients are more prone to myocarditis compared with the rest of population because abnormal dystrophin acts as a vehicle for different viruses [152,153]. During the early stages, it may remain undetected by echocardiography, which is unable to distinguish tissue structural changes, occurring without associated changes in LV ejection fraction, while an increase in cardiac troponin was found in only 20% of cases [154]. Additionally, according to American College of Cardiology/American Heart Association guidelines, myocardial biopsy should be used only for patients with unexplained newonset heart failure <2 weeks in duration associated with a normal-sized or dilated LV with hemodynamic compromise and should not be used for screening or follow-up [138]; it is limited by sampling error and observer expertise [155].

CMR diagnoses myocarditis using three types of images: T2-weighted (T2-W), early T1- weighted images taken 1 min after injection of the contrast agent (EGE), and delayed enhanced images (or LGE). T2-W is an indicator of tissue water content, which is increased in inflammation or necrosis, such as myocarditis and myocardial infarction. To enhance the detection of pathology on CMR, images should be obtained early and late after gadolinium injection. Higher levels of EGE are due to increased membrane permeability or capillary blood flow. LGE represent the amount of scar tissue. A combined CMR approach using T2-W, EGE and LGE has a sensitivity of 76%, a specificity of 95.5% and a diagnostic accuracy of 85% for the detection of myocarditis [156]. Myocarditis, missed by other noninvasive techniques, has been already described in DM using CMR, which may have significant implications in patients’ treatment, risk stratification and prognosis [153].

Fat deposits are often found around the heart. Epicardial fat is the adipose tissue accumulated between the visceral pericardium and the myocardium; it has a variable distribution, being more prominent in the atrioventricular, interventricular grooves and right ventricular free wall, and is nourished by the coronary arteries [157]. CMR is the technique of choice for fat quantification [157]. In a small case series, histological studies of hearts from DMD patients on autopsy identified fat infiltration [158].

Finally, CMR has the capability to characterize myocardial tissue using T1 mapping techniques. Patients with MD diseases are at risk for heart failure due to diffuse myocardial fibrosis and LV remodelling. Because native T1 values are raised in the presence of diffuse fibrosis and edema, T1 mapping by CMR is emerging as a potential tool to assess diffuse myocardial involvement. Native T1 values are increased in DMD and may serve as early markers of diffuse fibrosis [159].

Limitations of CMR

• Lack of availability and expertise;

• Difficulties in collaboration between cardiologists and radiologists, regarding the interpretation and clinical significance of CMR findings;

• Ignorance of neurologists regarding the diagnostic and prognostic information, offered by CMR; and

• High cost of examination.

Conclusions

Cardiac involvement is common in both MD patients and carriers. Currently used noninvasive techniques are low cost, widely available and do not require high expertise. However, they cannot identify the preclinical cardiac involvement in MD patients and carriers.

Due to its capability to detect myocardial changes before they will be clinically overt, CMR is the technique of choice for early, accurate diagnosis, treatment and follow-up of MD patients and carriers. However, further multicentre studies are needed before CMR will be included in the routine algorithm of MD patients and carriers.

Highlights

• Cardiac disease is common in MD and is not related to skeletal myopathy.

• High R/S in the right precordial and deep Q in the lateral leads are typical in DMD.

• Conduction defects are an important cause of sudden death in EDMD, DM1 and DM2.

• Fibrosis is an early finding in carriers and patients, even if echo is normal.

• CMR serves as sensitive index to early start cardioprotective treatment.
