Page 33

Recycling 2019 & Material Science 2019

July 22-23, 2019

Volume 3

Journal of Environmental Geology

Material Science and Nanotechnology

Global Recycling Summit

July 22-23, 2019 | Rome, Italy

6

th

International Conference on

&

Polarized Raman scattering of crystalline semiconductors cut off-axis

Bahram Roughani

1

and

Uma Ramabadran

2

1

Loyola University Maryland, USA

2

Kettering University, USA

A

unique approach to polarized laser Raman spectroscopy is introduced to investigate the structure and crystallinity of

Si wafers based on measured intensity profile and Raman intensity theoretical model. The orientation of the crystal in

our model is defined by two angles, the angle between (001) crystal axis and the lab z-axis, and the angle of rotation of the

crystallographic xy plane about the crystal’s z-axes. Raman selection rules for a given crystal symmetry govern the interaction

between the incident polarized laser and analyzed output. The scattered light intensity depends on the laser wavelength, the

cross-sectional area from which light is collected, the penetration depth of the laser, and the crystal orientation for specific

experimental geometry. An intensity map is generated when wafers of different geometry are rotated about the lab z-axis that

varies the angle between the fixed incident light polarization and the crystallographic axes. Calculated Raman intensity for LO-

and TO-modes for various crystallographic orientations when the polarizer and analyzer are both horizontal (HH) and when they

are perpendicular (HV) are presented. By increasing the crystal’s tilt Ѳ from crystal’s +z-axis to –z-axis and rotating the crystal

about the crystal z-axes for Ѳ from 0-45o a set of predicted profiles for various Si sample cuts are generated. Calculated profiles

for the combination of the LO and TO modes for (100), (110) and (111) silicon are in excellent agreement with normalized

experimental data published for these geometries. The changes in our Raman intensity profile provides an effective approach in

determining the degree of off-axis cut for single crystal Si. Similar studies using our unique polarized Raman scattering applied

to GaAs is underway. Our unique approach could be used as an alternate viable method to establish crystallographic orientation

for cut off-axis single crystalline semiconductors.

JEnvironGeol. |Volume3

ISSN:2591-7641
